You can send video from Astra Streaming Studio to YouTube over RTMP, but the available documentation does not confirm that Astra can create a portrait 9:16 feed or a YouTube Shorts-feed live. Set up the YouTube connection in Astra, then check YouTube Studio’s incoming preview; for a confirmed vertical presentation, use YouTube’s documented vertical or dual-format workflow and verify the vertical preview before going live.
Before you start
- Check channel eligibility. YouTube’s live-stream guidance requires a verified channel with no live-stream restriction in the previous 90 days. The minimum age for live streaming is 16. See YouTube’s live-stream help for current requirements.
- Install Astra Streaming Studio. Its Google Play listing describes an Android app with H.264/AAC encoding, RTMP and RTMPS streaming, and live camera and screen capture. The listing reports an update date of 31 October 2023; it does not document a portrait canvas or YouTube vertical-stream controls. View Astra Streaming Studio on Google Play.
- Have a stable connection and keep your stream key private. Use the server address and key shown in your own YouTube Studio session, not values copied from someone else’s setup.
Connect Astra Streaming Studio to YouTube
The app-specific steps below are an RTMP workflow outline corroborated by an independent Android setup walkthrough published 4 August 2026. Astra’s available documentation does not establish every current label or screen in the app, so follow the options shown in your installed version.
- In a browser, open YouTube Studio and go to Create > Go live to enter Live Control Room. Create a stream or select an existing one.
- In the stream’s settings, copy the current YouTube server or ingest address and stream key. Treat the key like a password: do not publish it, show it on screen, or send it to anyone who does not need it.
- Open Astra Streaming Studio on your Android device. Configure a stream destination, choose RTMP (or RTMPS if that is the option supported by your YouTube setup and shown in Astra), and enter the server address and key from YouTube Studio.
- Select the configured stream in Astra and start transmitting. The independent walkthrough describes selecting the configured RTMP stream and starting it from the app; exact controls may vary by app version. See the Android-to-YouTube setup walkthrough.
- Return to YouTube Studio and wait for the incoming feed. Check the preview, stream status, framing, sound, and orientation before making the broadcast public or sharing it.
How to get a vertical YouTube live
Sending a feed to YouTube over RTMP is not, by itself, proof that the result is a 9:16 vertical live. The Astra Google Play listing confirms RTMP/RTMPS and capture capabilities, but does not say that the app offers a portrait canvas, a dedicated vertical stream key, or compatibility with YouTube’s encoder-based dual-stream path. Do not assume Astra alone will place a broadcast in the Shorts feed.
Option 1: Use YouTube Live Control Room’s vertical layout
YouTube documents a dual-format Live Control Room workflow that can provide horizontal 16:9 and vertical 9:16 presentations. The vertical version defaults to a center crop; YouTube also documents fit-to-phone-width and stacked layouts. Layouts can be edited before going live and adjusted during a stream when the broadcast was initially created through YouTube’s editing canvas. Check the current vertical preview and choose a layout that keeps faces, important action, and any on-screen text in frame.
Do these 3 things before closing this tab:
1Repair Windows errors before they cause bigger problems2Scan for outdated or missing drivers - takes under a minute3Clear out junk files and repair common Windows errors#1 Best Overall
- Read Before You Buy — No Video Output: These adapters support charging and USB 2.0 data transfer, but cannot transmit video signals. Except for standard USB webcams (which use USB data only), they are not compatible with HDMI/DisplayPort cables, video-capable USB-C hubs, or docking stations with video output.
- Convert USB-A Ports to USB-C: Designed to connect USB-C earphones, cables, flash drives, card readers, and other USB-C accessories to standard USB-A ports. Plug-and-play with no drivers or software required.
- Aluminum Alloy Housing: Built with a sturdy aluminum alloy shell that aids in heat dissipation and protects against daily wear and scratches. Designed to maintain a stable and secure connection.
- Compact & Travel-Friendly: The ultra-compact design allows the adapter to stay plugged into your device without blocking adjacent ports or adding bulk, reducing wear and tear on your original USB ports.
- 12-Month Warranty: Backed by a 12-month manufacturer warranty for peace of mind. Designed to meet strict quality control standards for reliable everyday performance.
Option 2: Send separate horizontal and vertical feeds from an encoder
YouTube’s encoder workflow uses RTMP(S) and a second stream key for the vertical feed. Set up both feeds before starting, and send the matching format to each key. YouTube says a vertical format cannot be added after the stream has started. The available Astra documentation does not establish that Astra supports this second-key arrangement, so confirm the capability in the current app before relying on it.
Choose based on the source and audience
- Portrait-first source: A native vertical composition can keep a subject large on a phone screen. Confirm that the encoder and YouTube workflow accept that portrait feed; do not assume a setting exists in Astra.
- One landscape source, both audiences: YouTube’s vertical canvas may crop or rearrange the horizontal presentation. Preview the result carefully, especially when the subject moves near the edges or text sits in the margins.
- Desktop and TV viewers matter: Dual-format output can serve horizontal viewers as well as viewers in the Shorts feed, but it involves layout choices or a second encoder feed and key. Decide which presentation is primary before configuring the stream.
What viewers and channel owners should expect
According to YouTube’s current live-stream help, viewers using the Shorts feed on mobile see the vertical version, while other viewers see the horizontal version in a dual-format stream. Both formats use the same live URL and chat. Vertical lives can be discovered in Shorts and support memberships, but YouTube lists limits: no clickable links in chat or the channel description, no pre-roll or mid-roll live ads, and no 4K bitrate streaming on the YouTube app. Live Control Room provides combined metrics; vertical-only metrics become available after 24 hours. These details can change, so consult YouTube’s current guidance when planning a broadcast.
Rank #2
- 5-in-1 USB-C Hub: Experience comprehensive connectivity featuring a Power Delivery input, two USB-A 2.0 ports, a USB-A 3.0 port, and an HDMI port. (Note: The USB-C power delivery input port is only for connecting an external wall charger to power your laptop and cannot power peripheral devices.)
- 90W Pass-Through Charging: Achieve optimal charging with 90W pass-through power to your laptop, supported by a total input of 100W, with the hub reserving 10W for operational efficiency. (Note: Wall charger not included.)
- Quick Data Transfers: Accelerate your productivity with rapid data transfers using a high-speed 5Gbps USB 3.0 port and two 480Mbps USB 2.0 ports.
- 4K HDMI Display: Enhance your visual experience with a hub capable of delivering 4K resolution at 30Hz in both mirror and extend modes. Please note that this hub is compatible with MacBook (macOS 12 and newer), Windows 10 and 11, ChromeOS, and laptops equipped with DP Alt Mode and Power Delivery. Note: This device is not compatible with Linux.
- What You Get: Anker USB-C Hub (5-in-1, 4K HDMI), welcome guide, 18-month warranty, and our friendly customer service.
Troubleshooting
YouTube does not receive a signal
- Check that Astra is set to RTMP or RTMPS as appropriate, and that the server address and key match the current YouTube Studio stream.
- Make sure the stream has been started in Astra and that the selected destination is the one you configured.
- If you regenerated or changed the key in YouTube, update Astra with the new value. Never post the key publicly while troubleshooting.
YouTube receives video, but it is not vertical
- Confirm the vertical presentation in YouTube Studio’s preview rather than inferring it from the phone’s orientation.
- Use YouTube’s documented vertical canvas or dual-stream encoder setup if available to your workflow. Astra’s listing alone does not establish portrait output or dual-stream support.
- For dual-stream encoding, confirm that the vertical feed was configured before going live and is being sent in the format expected by its key.
The vertical crop cuts off the subject or text
Review the selected canvas layout in YouTube Studio. Try center crop, fit-to-phone-width, or stacked where available, and adjust the source composition so essential content remains within the vertical frame. Preview again before relying on the broadcast.
Audio or picture is missing or inconsistent
Check Astra’s selected camera or screen source, microphone and audio input, and the preview in YouTube Studio. Confirm the app has the Android permissions required for the sources you intend to capture. The available app listing describes capture and encoding capabilities but does not provide a full troubleshooting manual.
The Tool Desk
Outbyte Driver Updater FREEScan for outdated or missing drivers - takes under a minuteDriver Scan →Outbyte PC Repair FREERepair Windows errors before they cause bigger problemsFix Now →Rank #3
- Sleek 7-in-1 USB-C Hub: Features an HDMI port, two USB-A 3.0 ports, and a USB-C data port, each providing 5Gbps transfer speeds. It also includes a USB-C PD input port for charging up to 100W and dual SD and TF card slots, all in a compact design.
- Flawless 4K@60Hz Video with HDMI: Delivers exceptional clarity and smoothness with its 4K@60Hz HDMI port, making it ideal for high-definition presentations and entertainment. (Note: Only the HDMI port supports video projection; the USB-C port is for data transfer only.)
- Double Up on Efficiency: The two USB-A 3.0 ports and a USB-C port support a fast 5Gbps data rate, significantly boosting your transfer speeds and improving productivity.
- Fast and Reliable 85W Charging: Offers high-capacity, speedy charging for laptops up to 85W, so you spend less time tethered to an outlet and more time being productive.
- What You Get: Anker USB-C Hub (7-in-1), welcome guide, 18-month warranty, and our friendly customer service.
Or let it run in the cloud
If your goal is to keep uploaded video running as a 24/7 YouTube stream rather than broadcast a live phone camera, StreamNeo is a separate cloud option: upload a recording or build a playlist, add your YouTube stream key, and go live. Nothing has to stay on at home; it streams uploaded video at the quality supplied, up to 4K 60fps, for one flat price per slot, and it can automatically recover if YouTube drops the stream. The first day is free with no card. Monthly is $9.99 per month. Start with the free StreamNeo day.
